GER-UV-LED
GER-UV-LED 8W45-S24C / Kaset içi UV-LED
Özellikler
| Power Suplier | :DC/DC Converter or Led Driver |
| Power Suplier Model | :DC-DC24V700mA (24VDC input - 700 mA 9-56VDC Output) |
| Power | :16 Watt (90 cm - 12 LED) / 8 Watt (45 cm - 6 LED) |
| Radiant Power | :200mW / 100mW |
| Lifetime | :60000 h |
| Dominant Wavelength | :275 nm |
| Mercury (Hg) Content (Nom) | :No |
| Module Current | :0.700 A (90 cm) / 0.350 A (45 cm) |
| System Voltage (Nom) | :20.4 Volt |
| Dimension | :450 mm x 16 mm Module x 2 (Parallel Connection) |
